2. Getting to know the projector.
Name Pcs Description Purpose
LAN 1
Standard RJ 45 connector For Projector Control
DP 2
Standard display port
For Projector Input
DL-DVI-D 2
Dual DVI-I 1.0 (DVI_D Functionallity).
For Pr ojector Input. These connectors can also b e used to
form one uniform image by feeding half of the im age into
each connector. HDCP compliant for sources up 165 M hz
HDMI 1
Standard HDMI 2.0
For Projector Input
HDBaseT 1
Standard RJ45 8P8C Connector For Projector Control
SDI
2
SDI1 is Input, SDI 2 is pass through.
(out)
For Projector Input
Connectors
2.10 Color Wh eels
About
The F 70 Projector is delivered with a standard Color wheel, that is suitable for most appli
cations.
Other colorwheels are available upon request.
Consult Barco sales office or a service partner in order to find the m ost suitable c olorwheel for the specific ap plication.
2.11 Optional Accessories
Rigging Frame
Item Numb er Item Description
R9802224 F70/F90 Multifunctional Frame.
The F70 Rigging fram e is a rugged, easy to install frame, designed to streamline the process of installing one or more projectors.
When installed i the frame, the projector:
• can be rotated around the x, y and z axis, in order to obtain a seamless adjustment in applications using multiple projec tors.
• Can be ins talled from a truss or a pedestal.
• Can be easily stacked one on top o f another, for instance a dual or multichannel installations.
Flight Case
F70 use the same Flight cas e as the F90 series projectors.
Item Numb er Item Description
R9801195
F90 flight case.
601–426 F70 SERIES 24/10/2017 23
