2. Getting to know the projector.
Projector controlling
When the address is set, the projector can be controlled now:
• with the RCU: only for addresses between 1 and 31.
Broadcast Address
Every projector has a broadcast (common) address ’0’ or ’1’. The default address is ’0’.
The choice between ’0’ and ’1’ can be selected in the G UI: “System S ettings” → “Comm unication” →“IR Control “.
Placing new batteries in the remo te control or plugging t he remote to a projector via a cable will autom atically
reset the address back to its default value ’0’.
2.8.2 Displaying and Programming addresses into the RCU
Displaying the Projector Address on the Screen.
1. If the pro jector is on, press the menu key and navigate to the Status page. The projector address and the broadcast address can
be seen under the C omm unication heading.
The projector’s address is displayed on the LCD status screen and / or the OS D.
How to Program an Address into the RCU?
1. Press the Address button until the Button pressed indicator lights up continuously (proximately 5 seconds).
2. Enter the address w ith t he digit buttons within the time the indicator lights up (also proximately 5 seconds).
Note: That address can be any value between 0 and 31.
Tip: A few examples:
To enter address 3, press "3" digit button on the RCU to set the RCU’s address to 3 and wait until the button pressed
indicator is out. Alternatively, you can also press “0” and “3”. This way, the button pressed indicator goes out immediately.
To enter address 31, then press “3” and “1” on the digit button on the RCU and th e button pressed indica tor g oes out
immediately.
2.9 Connector p anel
General
The source input pa nel is located at the back of the projector. For s ource specifications, s ee table below.
Image 2-10
Name Pcs Description Purpose
DMX IN 1 DM X 512 input
For Projector Control
DMX OUT
1 D M X 512 output
For Projector Control
RS-232
1 9–pin D B9 connector
For Projector Control. A llows for wired rem ote control and
monitoring of many projector functions used in installation
environments
Sync 3 BNC Sy nc Port IN/OUT; B idirectional
mini-DIN (1x 3D sync O ut, and 2x
Sync In/Out)
For Pro jector Con trolThis is m ainly used in m ultiple projector
installations with requirement of synchronization between
the units
Tr igger
3 (one in
front, two
on rear
panel)
12VDC - 0,5A (6W) For Con trolling Peripherals, like m otorized screens, curtains
etc. Give 12V output when projector are switched on
RC 1 Jac k connector for wired re mote For Projector Control
USB 3 US B 2.0 type A , 4 pin( 2x Rear and
1x Front)
For Software upgrade
22 601–426 F70 SERIES 24/10/2017
