5. Getting started
5.1.3.1 RS-232
Specifi ca tions
Param eter Value
RS-232 connector 1 female DB9 connector (RS 232-in) for projector control and
debug
5.1.3.2 LAN/Ethernet
Specifi ca tions
Param eter Value
Ethernet connector
1 RJ45 Connector for projector control (not content)
Protocols
DHCP, TCP/IP, UDP/P
Speed 10/100 Mbit/1000Mbit
5.1.3.3 USB-A port
Specifi ca tions
Parameter Value
USB connector
Type A
Function
Firmware upgrade u sing USB sticks
Power
Power 5V, m ax 1,5A ( out)
Standard USB 2.0
5.2 P ower up the projector
CAUTION: Sources should always be connected before the projector is powered up
CAUTION: Use only power cords following the unit, designed for your projector m odel. Do not use unautho-
rized replacements. Do n ot use pow er cords which are dam aged .
Power up the projector using the keypad or remote
1. Connect the line cord to the projector.
2. Plug the 3–pronged cord into a ground ed AC outlet.
The projector will begin warming up, and the backlight of the Standby /power button are fl as hing white.
3. When the backlight on the standby button are constant white, the pr ojector are in standby mode, ready to be switched on.
4. Press the standby button on the keypad or the
power button on the remote to bring the projector u p to on mode.
The power button backlight on the keypad will flash b lue while the projector is warm ing up.
5. When the power button backlight is steady blue, the projector is ready for use.
5.3 Power down the projector
Power down using the keypad or remote
1. Depress and hold the pow er button o n the keypad or rem ote for four (4) seconds.
The Pr ojector is now in cooling down phase.
2. When the pr ojector pane l is no longer illuminated, remove the mains power c ord from the projector.
44
601–426 F70 SERIES 24/10/2017
