AW00097603000 Pixel Data Formats
Basler aviator GigE 133
When the camera is set for Mono 12, the pixel data output is 16 bit data of the “unsigned short (little
endian)” type. The available range of data values and the corresponding indicated signal levels are
as shown in the table below. Note that for 16 bit data, you might expect a value range from 0x0000
to 0xFFFF. However, with the camera set for Mono12 only 12 bits of the 16 bits transmitted are
effective. Therefore, the highest data value you will see is 0x0FFF indicating a signal level of 4095.
This Data Value
(Hexadecimal)
Indicates This Signal Level
(Decimal)
0x0FFF 4095
0x0FFE 4094
0x0001 1
0x0000 0
