AW00097603000 Pixel Data Formats
Basler aviator GigE 135
When a monochrome camera is set for Mono 12 Packed, the pixel data output is 12 bit data of the
“unsigned” type. The available range of data values and the corresponding indicated signal levels
are as shown in the table below.
This Data Value
(Hexadecimal)
Indicates This Signal Level
(Decimal)
0x0FFF 4095
0x0FFE 4094
 
 
 
0x0001 1
0x0000 0
