Basler GigE CAMERAS User Manual

Pixel Data Formats AW00097603000
144 Basler aviator GigE
When the camera is set for YUV 4:2:2 Packed output, the pixel data output for the Y component is
8 bit data of the “unsigned char” type. The range of data values for the Y component and the
corresponding indicated signal levels are shown below.
The pixel data output for the U component or the V component is 8 bit data of the “straight binary”
type. The range of data values for a U or a V component and the corresponding indicated signal
levels are shown below.
The signal level of a U component or a V component can range from -128 to +127 (decimal). Notice
that the data values have been arranged to represent the full signal level range.
B
m-4
Y value for P
n-2
B
m-3
U value for P
n-1
B
m-2
Y value for P
n-1
B
m-1
V Value for P
n-1
B
m
Y value for P
n
This Data Value
(Hexadecimal)
Indicates This Signal Level
(Decimal)
0xFF 255
0xFE 254
 
 
 
0x01 1
0x00 0
This Data Value
(Hexadecimal)
Indicates This Signal Level
(Decimal)
0xFF 127
0xFE 126
 
 
 
0x81 1
0x80 0
0x7F -1
 
 
 
0x01 -127
0x00 -128
