AW00097603000 Standard Features
Basler aviator GigE 195
Sequence Advance
As explained above, a sequence set can only control the operation of the camera after its parameter
values were loaded into the active set. The loading into the active set and therefore the selection of
a sequence set as the current set for a specific image acquisition are performed according to the
selected sequence advance mode. The selection of a sequence set as the current set is always
linked to the frame start trigger signals unless software commands are used (see below).
Accordingly, a sequence advance mode provides a scheme for advancing from one sequence set
to the next as frames are triggered.
The following three sequence advance modes are available:
Auto sequence advance mode: Sequence set advance is automatically controlled by the
camera. The camera will cycle through the available sequence sets in ascending sequence set
index number as frames are triggered. Individual sequence sets can be used consecutively.
After one sequence set cycle is complete another one will start automatically.
For more information, see Section 10.10.1 on page 198.
Controlled sequence advance mode: Sequence set advance is controlled by a source that
can be selected. The available sources are automatic control by the camera (the "always
active" setting), an input line or the "disabled" setting allowing sequence set advance only by
software commands.The camera will cycle through the available sequence sets in ascending
sequence set index number as frames are triggered. After one sequence set cycle is complete
another one will start automatically.
For more information, see Section 10.10.2 on page 204.
Free selection sequence advance mode: Sequence set advance by selecting sequence sets
at will from the available sequence sets. The selection is controlled by the states of the input
lines.
For more information, see Section 10.10.3 on page 223.
Because the sequence sets only reside in volatile memory they are lost if the
camera is reset or switched off. If you are using the sequencer feature, you must
populate the sequence sets after each camera reset or startup.
Note also that sequence sets can not be saved in user sets.
