Standard Features AW00097603000
240 Basler aviator GigE
0 1024 2048 3072 4095
12 Bit Digitized Sensor Reading
0
1024
2048
3072
4095
12 Bit
Camera
Output
Fig. 58: Lookup Table with Values Mapped in a Linear Fashion
0 1024 2048 3072 4095
12 Bit Digitized Sensor Reading
0
1024
2048
3072
4095
12 Bit
Camera
Output
Fig. 59: Lookup Table with Values Mapped for Higher Camera Output at Low Sensor Readings
