4.1.2 Technical data, Junior II-E
Compressor unit Junior II-E
Performance characteristics
Medium Air
Suction pressure atmospheric
Operating pressure max. [bar] PN200 or PN300
Blow-off pressure, final pressure safety valve
[bar]
225 / 330
Setting pressure, pressure retention/non-re-
turn valve [bar]
160
Compressor block Junior II, manufacturing status 3
Delivery volume [l/min] measured using cylin-
der filling (10 l) from 0 to 200 bar, ± 5%
100
Speed [rpm]
2300
Drive motor type Three phase AC motor
Ambient conditions
Maximum permissible ambient temperature
[°C]
+5 ... +45
Location [m above sea level] 0 ... 1500
Explosion protection no
Maximum permissible inclination of the com-
pressor
5°
Weights and measures
Dimensions standard unit (L x B x H) [mm] 655 x 360 x 415
Dimensions unit with automatic condensate
drain (L x W x H) [mm]
760 x 430 x 480
Weight [kg] 53
Operating and auxiliary materials
Oil see Chapter 9.3.4 Lubrication oil, Page 80
Emissions
Noise pressure level [dB(A)] 84
Noise level [dB(A)] 97
Electricity
Standard operating voltage [V] 400
Standard frequency [Hz] 50
Tab. 8 Technical data, Junior II-E
