Bauer Compact-Line JUNIOR II-B - Technical Data about the Compressor Block; Technical Data Filter System; Technical Data about the Filter System

4.2.2 Technical data about the compressor block
Compressor block Oceanus, manufacturing status 1
Number of stages 3
Number of cylinders 3
Cylinder bore 1st stage [mm] 70
Cylinder bore 2nd stage [mm] 28
Cylinder bore 3rd stage [mm] 12
Piston stroke [mm] 24
Direction of rotation (looking onto the fly-
wheel)
left
Intermediate pressure 1st stage [bar] 6.5–7
Blow-off pressure of safety valve 1st stage
[bar]
9.9
Intermediate pressure 2nd stage [bar] 52-61
Blow-off pressure of safety valve 2nd stage
[bar]
80
Oil quantity [l] 1.3
Suction pressure / intake pressure [bar] 0 (atmospheric)
Tab. 14 Technical data about the compressor block
4.3 Technical data Filter system
4.3.1 Technical data about the filter system
Filter system
P21
Operating pressure max. [bar] 350
Pressure dew-point
<-20 °C, corresponding to 3 mg/m
3
at 300
bar
Filter content [l] 0.57
Classification as per the Pressure Equipment
Guideline
Vessel category II
Residual water content
<10 mg/m
3
Residual oil content
<0.1 mg/m
3
Tab. 15 Technical data about the filter system
