6.2.2 Installing the B-TIMER
Mount the B-TIMER on the filter housing of the filter to be monitored using a
fastener.
6.3 Connecting the unit to the electrical mains
DANGER
Danger to life due to electric voltages!
Contact with live parts can lead to death or serious injuries.
Work on the electrical unit may be carried out by an electrician only.
Make sure that the unit is tension-free for the necessary work.
1.
Follow the basic safety instructions, see Chapter 2.4.1 Fundamental safety in-
formation, Page 18.
2.
Observe the local electricity supply company’s regulations.
3.
Check for perfect protection line laying.
4.
Check that the motor voltage, switchgear voltage and frequency agree with
the mains voltage and mains frequency.
5.
Secure the unit properly. For this, use only slow-acting fuses.
6.
The customer must supply the required cabling, main fuse and a main switch
(power circuit breaker).
7.
Ensure that the main switch can be related distinctly and directly to the unit.
8.
For permanently fixed installations: Fit an isolator for isolation from the mains
having a contact opening distance of at least 3mm at each terminal.
6.4 Inspection of the unit
At the BAUER KOMPRESSOREN factory, components such as the compressor,
storage system and other accompanying components are subjected to a technical
partial acceptance inspection by the TÜV.
Before commissioning the unit, have it inspected at the installation site by a
qualified person or authorised inspection agency, see Chapter 2.8 Safety regu-
lations, Page 27.
