Setting the delivery volume
1.
In the setup mode, press the selection key until the corresponding sub-menu
is reached.
Ä
The filter icon blinks and “B" is shown.
2.
Refer to the order documents for the delivery volume of the compressor in l/
min.
3.
Press the input key for 3 seconds if you want to change the setting.
Ä
The 1stposition starts blinking.
4.
Use the selection key to set the 1stposition as desired.
5.
Confirm the change using the input key.
Ä
The 2ndposition starts blinking.
6.
Set the 2nd and 3rdpositions accordingly.
Setting the operating pressure
1.
In the setup mode, press the selection key until the corresponding sub-menu
is reached.
Ä
The filter icon blinks and “C" is shown.
2.
Press the input key for 3 seconds if you want to change the setting.
3.
Use the selection key to set the operating pressure (200 bar, 200 bar or
200/300 bar).
4.
Confirm the change using the input key.
Setting the operating hours
1.
In the setup mode, press the selection key until the corresponding sub-menu
is reached.
Ä
The filter icon blinks.
2.
Press the input key for 2 seconds if you want to change the setting.
Ä
The last position starts blinking.
3.
Use the selection key to set the last position as desired.
4.
Confirm the change using the input key.
Ä
The next position starts blinking.
5.
Set the next positions accordingly.
