Adjusting the timer
Only competent personnel may set the timer. For more information, contact the
BAUER customer service department, see Chapter 1.2.7 Contact data BAUER
KOMPRESSOREN, Page 13.
The following timer is fitted to units having an electric motor:
NOTICE
Material damage due to unsuitable condensate drain intervals!
Excessively short condensate drain intervals lead to the flooding of the separator
and damage the downstream units.
In case of humid air and humid gas, set the condensate drain intervals accord-
ingly lower or get their settings configured.
The timer controls the automatic condensate drain and is an industrial timer with a
changeover contact. The automatic condensate drain is controlled using the set-
ting regulators t1 and t2 for pulse time and pause time. The sliding switch is set to
pulse start. t1 is set in the factory to 15 minutes, t2 is set to a blow-off time of 6
seconds.
