07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 8-29
Removal/Replacement Procedures Disassembly/Reassembly
5. Verify that the configuration option is set as desired and modify if
necessary (see “Modifying the Configuration Option Settings” on page
5-2).
6. Check the backup battery voltage reading per “Automatic Test Mode 1:
Calibration Mode 1” on page 9-14, step 10.
7. Perform the Operational Checkout in Chapter 10, “Operational
Checkout”.
Tube Guide Shim Installation
Required Parts:
Q Air Sensor Tubing guide shim (part no. 722003396)
Q Loctite Prism 454 adhesive (part no. 722003397)
Q Cellophane tape
Note: Open the pump head door and check for a white tubing guide shim or a letter
“A” on the door, opposite the air sensor. When the shim or letter “A” is
present, it is NOT necessary to perform this procedure.
1. Clean the tube guide area on the door with a small paint brush soaked in
a solution of dishwashing detergent and rinse with clean water. Use an
air source that is free of oil to dry the tube guide or allow it to air dry.
2. Lay the pump on its side opposite the pump head. Place the tube guide
shim on the tube guide and note the surfaces making contact with the
tubing guide for adhesive application. To handle the shim, press a 3-inch
piece of cellophane tape onto the shim lengthwise. Use the tape to lift the
shim from the door. Save the tape and shim combination.
3. Use the applicator on the tube to apply a thin, uniform layer of Loctite
Prism 454 adhesive to the tube guide surfaces to which the shim is to be
bonded. To achieve a good bond you must apply adhesive to all of the
shaded areas (See Figure 8-4).
Make sure the pump is not plugged into AC power.
