7 Automatic Test Modes
7-10 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
The RATE/VTBI keys and number keys 7, 8, and 9 are not accepted. Other
specifications are the same as during normal operation.
Automatic Test Mode 5: Display Check Mode
All the LCD segments, LEDs and icons turn on sequentially for a visual check
each time the
STOP key is pressed. At any point in the sequence the SEC
START
key may be pressed to return to the beginning of the sequence.
Automatic Test Mode 6: Time Information Display Mode
In this test mode, the cumulative time values are displayed sequentially each
time the
SEC RATE key is pressed. The test mode first displays the
cumulative Power On time, then the time on battery and finally, the time that
the pump was actually pumping. It should be noted that the first six digits
from the left are the time in hours and the two digits on the right are the time
in minutes. Therefore, the display 0001 02:21 represents 102 hours and 21
minutes.
Automatic Test Mode 7: Pumping Sensor Monitoring Mode
In this test mode, the motor current and occlusion sensors may be monitored
during pumping. During pumping, the motor current is displayed in the PRI
VTBI location, the upstream occlusion detector reading in the SEC RATE
location, and the downstream occlusion sensor reading in the SEC VTBI
location. When the pump is stopped, all of the displayed values return to
normal.
2
3 000
3
250 000
4
499 100 0 0
5
1401 100 0 0
6
1999 100 0 0
Key
Number PRI RATE PRI VTBI SEC RATE SEC VTBI
This is an automatic test mode for testing the device during manufacturing only.
This mode must not be used on patients.
