07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 7-9
Troubleshooting Automatic Test Modes
Automatic Test Mode 3: Manufacturing Test Mode
The initial display in this automatic mode is for a PRI RATE of 1999 mL/hr,
PRI VTBI of 3998 mL, SEC RATE of 500 mL/hr, and SEC VTBI of 100 mL.
Pressing the
TIME key changes the primary settings as follows:
In each combination, the primary and secondary rates and VTBI can be
manually altered.
The pump stops automatically one hour after the
PRI START key was
pressed. While the pump is running, the air sensor and the upstream and
downstream occlusion sensors are disabled.
Automatic Test Mode 4: Aging Mode
While the pump is stopped, pressing any numbered key (0 - 6) programs a
preset rate/VTBI combination as follows:
This is an automatic test mode for testing the pump during manufacturing only.
This mode must not be used on patients because the downstream occlusion,
upstream occlusion and air sensors are disabled.
PRI RATE PRI VTBI SEC RATE SEC VTBI
999 1998 500 100
499 998 500 100
250 500 500 100
125 250 500 100
10 20 500 100
This is an Automatic Test Mode for testing the pump during manufacturing only.
This mode must not be used on patients because the rates and VTBI settings
cannot be altered.
Key
Number PRI RATE PRI VTBI SEC RATE SEC VTBI
0
500 3000 999 6000
1
499 0 999 1
To Next Page
