5 Modifying the Configuration Option Settings
5-2 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
Modifying the Configuration Option Settings
1. Turn off the pump.
2. While pressing the STOP key and PANEL LOCK switch, press the
ON-OFF/CHARGE key. The following occurs:
2.1 The MODIFY CONFIG message appears in the Message
Display.
Note: When the message LOCKED OUT is displayed, the configuration option set-
tings can be changed only via computer control. See the Programmer’s Man-
ual for additional information.
2.2 The parameter descriptor appears in the first line of the
Message Display when the
NEXT or SEC START key is
pressed.
2.3 The current parameter setting appears in the second line of the
Message Display.
2.4 The programming display is blank.
3. Press the NEXT or SEC START key to advance to the desired parameter.
The parameters appear in the order shown in Table 5-1.
4. To change the settings, enter the desired value on the front panel. The
selected numeric value is displayed in the Primary Rate display until the
value is locked in by the
PRI START key, or the next parameter is
displayed by pressing the
NEXT or SEC START key.
Note: The alarm log for the pump can be cleared via the configuration option. See
Table 5-1.
5. To lock in the selected value, press the PRI START key. The selected
value is then displayed in the Message Display. To move on to the next
parameter, press the
NEXT key or SEC START key.
6. To exit, press the ON-OFF/CHARGE key.
Table 5-1 Configurable Settings
Parameter Description Setting Options
Factory
Settings
1. Alarm Log: Clear alarm/failure codes of the pump. Select 1 to clear
the pump’s alarm log.
N/A N/A
To Next Page
