11 Overview
11-10 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
Table 11-5 Parts List - Pump Head Door Assembly (F049120021)
Item Svc. Part # Mfg. Part # Description Qty
1 F049120021 F049120021 Pump Head Door Assy 1
2 CHNDP100.F S047944 LATCH, Door Assembly 1
3 JHNDP100.B S048021 LATCH, Door 1
4 LPLTP106.A S048440 PLATE, Door Latch Label 1
5 LXRZ1003.A S048882 E-RING, Door Latch 1
6 MSPRC101.D S048500 Spring, Door Latch 1
7 OiCMP32T.H S048896 Washer, M4, 0.8T 1
8 OiCMP32T.L S048897 WASHER, M4.2, 0.1T 2
9 PMAGT100.B S048498 MAGNET, Door Latch 1
10 TLABH109.A 07-26-01-179 Label, Push 1
11 S050051 S050051 DOOR, Pump Head 1
12 LBSHZ101.A S048489 Bumper, Door 2
13 LBSHZ101.C S048502 BUSHING, Door Latch 1
14 LPiNS101.C S047417 PIN, Door Hinge 2
15 LPLTM106.A S048445 Plate Safety Clamp, 1.2 mm Thickness 1
16 LPLTM106.B S048441 Cover, Back Plate 1
17 S048493 S048493 PLATE, BACK 1
18 MSPRC101.C S048499 SPRING, Back Plate 5
19 PAJS1002.A S048494 STOP, Occlusion Detector 2
20 PCUSG101.A S048504 Door Bumper 4
21 PZETE100.C S048506 Film, Plate Insulation 1
22 072626930 072626930 Warning Label FG6X01 Pump 1
23 TLABZ110.B S047929 LABEL, Tube Loading A 1
24 TLABZ110.C S047930 LABEL, Tube Loading B 1
25 XBPSD20P.C S048933 SCREW, Pan Head, M2X8 w/ washer assy 2
26 XBSUZ30P.A S048987 SCREW, Flat Head, M3X6 7
27 XBSUZ30P.F S048966 SCREW, Flat Head, M3X10 1
To Next Page
