07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 8-1
Chapter 8
Chapter 8 Removal/Replacement
Procedures
Overview
This section of the manual includes a list of tools and test equipment required
for performing maintenance, procedures for removing and replacing
subassemblies once the cause of a malfunction has been determined, and
procedures for calibration after component or circuit board replacement.
Detailed exploded views of the pump are provided in Chapter 11, “Illustrated
Parts Breakdown”.
Preparation for Maintenance
Tools and Test Equipment
The following tools and test equipment are required to perform the procedures
contained in this section. Since all fasteners on this pump are metric, ensure
that all tools used are for metric fasteners. Tightening torques on certain
screws are specified in kgf-cm and in-lb for your convenience. The values in
in-lb are approximate.
This device should be repaired only by Baxter authorized service personnel or
Baxter-trained hospital biomedical engineering personnel.
Use only Baxter replacement/service parts. Installation of parts other than those
available from Baxter may affect product performance. The use, by any party, of
non-Baxter parts in the repair, renovation, repackaging or restoration of a
Baxter device means that person or entity is the manufacturer of that device.
Any liability arising from the use of non-Baxter parts is assumed by the entity
performing such work. Baxter’s warranty is immediately null and void where
non-Baxter parts are used to repair Baxter devices.
