07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 8-15
Removal/Replacement Procedures Disassembly/Reassembly
7. Secure the replacement air sensor to the pump head (tightening torque of
2 kgf-cm or 1.7 in-lbs) and reconnect CN811.
8. Route the wires to their original location and replace any cable ties that
were removed in step 2. The number of ties and their locations should
approximate the original configuration (refer to “Routing of Internal
Wiring” on page 8-33).
9. Trim the ends of all newly added cable ties so that they are flush with the
cable tie buckles. If the ground wire screw was loosened in step 2,
tighten the ground wire screw to 7 kgf-cm (6.1 in-lb).
10. Perform the calibration in “DC Line Voltage Calibration” on page 9-1
and “Air Sensor Calibration” on page 9-6.
11. Perform the Operational Checkout procedures in Chapter 10,
“Operational Checkout”.
Replacement of Force Sensing Resistor
1
(FSR) Devices for Tube Misloading Sensors
Note: When the repair requires replacement of the FSR, replace the pair of FSRs.
1. Remove pump door cover in accordance with “Replacement of Pump
Head Door Cover” on page 8-9.
2. Separate the front and rear housings (“Separation of Front and Rear
Housings” on page 8-5).
3. Disconnect the tube misloading sensors (Figure 11-6 , items 10 and 11)
from the connector at rear top of the pump head assembly by pulling
their connector housings. Do not remove them by pulling the film
portion.
4. Open the pump door.
5. Remove two Phillips screws (Figure 11-7 , item 16) which secure the
upstream occlusion sensor (Figure 11-7 , item 9) to the pump head base
plate.
6. Pull and rotate the sensor 45° clockwise and carefully remove it from the
pump head base plate.
7. Remove the mounting block for the latch pin (Figure 11-6 , item 1).
1. Interlink Electronics
CAUTION
Do not scratch the ribbon connectors located above the sensors. Scratches can
damage the connectors.
CAUTION
Do not damage the base plate or the surface of the other tube misloading sensor
with the tool. Do not reuse the removed tube misloading sensor.
