7 Failure Identification Code Troubleshooting Table
7-12 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
Table 7-3 Failure Identification Codes
Code Cause Checks Corrective Action
0 No alarms or failures. No action necessary.
1 Air bubble detected in a Run
mode.
Check for air in tubing. Ensure set
is correct type and is properly
loaded. Ensure set tubing is not
scratched or deformed.
Expel air in tubing. Replace or
reposition set when tubing is
flattened or scratched. Clean air
sensor in accordance with Chapter
6, “Routine Maintenance” when
dirty.
Perform “Automatic Test Mode 2:
Calibration Mode 2” on page 9-15
steps
2 through 6.
When values are not within
specification, recalibrate or
replace the air sensor.
2
3
Downstream occlusion was
detected.
Check for scratched or deformed
tubing. Verify that ambient
temperatures are between 60° and
100° F (15.5° and 37.7° C).
Ensure set is correct type and is
properly loaded. Check for spilled
solution in sensor region.
Remove downstream occlusion
and reposition the tubing. Clean
occlusion sensors in accordance
with “Cleaning” on page 6-1 when
dirty. Raise or lower temperatures
if necessary.
Perform “Automatic Test Mode 1:
Calibration Mode 1” on page 9-14,
steps
1 through 9.
Perform “Safety Slide Clamp
Mechanical Calibration” on page
9-4.
4
5
Upstream occlusion was detected. Check for spilled solution in
sensor region. Ensure set is proper
type and is properly loaded.
Remove upstream occlusion and
reposition tubing. Clean the sensor
with cotton swabs dampened with
one of the agents listed in Table
6-1. Remove fibers or foreign
particles. Do not use hard
instruments for cleaning.
Ensure ambient and solution
temperatures are between 60° and
100° F (15.5° and 37.7° C).
Raise or lower temperatures.
Perform the appropriate steps
from “Automatic Test Mode 1:
Calibration Mode 1” on page 9-14
related to upstream occlusion.
Reading displayed in pump’s PRI
RATE window must be within
3242 and 3314. If not, recalibrate
or replace the sensor.
Check for damage to door latch
and hinges.
Replace any damaged parts.
