07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 8-23
Removal/Replacement Procedures Disassembly/Reassembly
Replacement of Battery
1. Turn off and unplug the pump.
2. Remove the 4 screws (Figure 11-4 , item 19) on the battery compartment
cover.
3. Slide the battery out of the rear housing.
Note: Lead batteries must be recycled or disposed of properly. Contact Federal or
State environmental agencies for information on recycling and disposal
options.
4. Disconnect the two female connectors from the battery terminals.
5. Reassemble the battery into the pump in reverse order. Tightening torque
for the four screws is 9 kgf-cm (7.8 in-lb).
6. Perform the Self Test (“Self Test” on page 10-3) and Battery Check
(“Battery Check” on page 10-10).
Replacement of Main Power Fuse
1. Plug the pump into an AC power outlet.
2. Check if the Plug Icon is illuminated. If it is not, replace the fuse.
3. Remove the power plug from the AC power outlet.
4. Remove the power cord cover on the back of the pump and unscrew the
fuse caps with a small screwdriver.
5. Remove the fuses and check them for electrical continuity with an
ohmmeter. If necessary, replace with a new fuse of the same value, type
and voltage.
CAUTION
Be sure to match the polarities of the female connectors.
CAUTION
Red wires (+) must be connected to red marked (+) battery terminal. See the
battery label on the underside of the battery cover. The battery must be placed
with its connectors up. (See Figure 11-4 ). The wires must be routed in the battery
compartment so that they run between the battery and the boss for the housing
screw.
CAUTION
Be sure to place the cushion (Figure 11-4 , item 10) around the boss such that its
surface becomes flush with the boss.
CAUTION
Be careful not to pinch wires between the front housing and battery compartment
cover.
