07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-1
Chapter 11
Chapter 11 Illustrated Parts Breakdown
Overview
This section includes illustrations and parts lists required to identify any
replaceable part in the FLO-GARD 6201 Volumetric Infusion Pump. Each
illustration is keyed to a parts list, which lists each component shown in the
figure by part number and description. The quantity per assembly is also
shown. To obtain replacement parts, contact product service. The first column
shows the figure and item number of each part. The second column is the
Product Service part number. The third column is the manufacturer’s part
number, and the last column is the quantity per assembly.
