07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-7
Illustrated Parts Breakdown Overview
Table 11-4 Parts List - Rear Housing Assembly
Item Svc. Part # Mfg. Part # Description Qty
1 F049120008 F049120008 Pole Clamp Assembly 1
2 4009390001 4009390001 COVER, Comm. Port 1
3 GCOVH101.A F044624005 COVER, EPROM Access 1
4 GFTAB101.A F042624004 Battery Compartment Cover 1
5 JKNBZ100.C F049620011 KNOB, Volume Control 1
6 JKNBZ101.C 6009590024 KNOB, Panel Lock Sw. 1
7 F049211002 F049211002 NUT, Comm. Port 2
8 PCUSS102.A F044630003 CUSHION, Battery 1
9 PGUMM103.C F044630005 SEAL, Batt. Comprtmnt 1
10 PGUMM103.F F044620005 CUSHION, Batt. Comprtmnt 1
11 QCNW1092.A F043140004 HARNESS, Comm. Port 1
12 QCNW1094.A F042140006 Battery Harness 1
13 QFSB1221.A 5009425001 FUSE, Main, 0.5A, 250V, Slow Blow 2
14 QFSB4451.A 5009425002 FUSE, Battery, 2A, 125V 1
15 QSOCA101.A 5009410002 AC Receptacle 1
16 F044810003 F044810003 LABEL, Panel Lock & Alarm Volume 1
17 07-26-B1-087 07-26-B1-087 LABEL, Battery 1
18 UBAT1010.A 5009480001 Battery, Lead-Acid, NP2-12 1
19 XBBSD40P.D 4009310012 SCREW, Binder Head, M4X10 4
20 4009310006 4009310006 SCREW, Pan Head, M2.6X8 2
21 XBPBN40P.B 4009310004 SCREW, Pan Head, M4X10 3
22 XBPSD30P.L 4009310007 SCREW, Pan Head, M3X8 1
23 XBSBN30P.A 4009310013 SCREW, Flat Head, M3X10 2
24 PZETL102.G 3004010004 FILM, EPROM Access Cov. Insulation 1
25 GCOVH101.B F043624003 COVER, Power Cord 1
26 LXBZ1004.A 4004310023 SCREW, Pan Head, M4X63 6
27 5009410001 5009410001 AC Power Cord 1
To Next Page
