8 Preparation for Maintenance
8-2 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
Note: Reset the configuration options in accordance with “Modifying the Configura-
tion Option Settings” on page 5-2 after performing any repairs. This is espe-
cially important after replacing the EPROMs, and after the occurrence of
failure codes 49 or 94.
Recording the Configuration Option Settings
It is necessary to record the configuration option settings and the alarm log
data before beginning maintenance procedures so that the pump can be
reconfigured properly when maintenance is completed. See “Reviewing the
Configuration Option Settings” on page 5-1 for more information.
Note: When the battery, EPROMs or a circuit board is disconnected or replaced, or
a calibration is performed, all the configuration options must be reset. See
“Modifying the Configuration Option Settings” on page 5-2.
1. Turn on the pump. Enter the configuration review mode by pressing the
TIME and TOT VOL/STATUS keys simultaneously. Hold the keys for 1
second.
2. Press the NEXT or SEC START key to access each parameter
sequentially. Record the configuration settings.
3. Exit the configuration inspection mode by pressing TIME and TOT VOL/
STATUS
again or press the STOP key.
Test Equipment Tools
• Digital Voltmeter
•DC Ammeter
•10Ω, 10W resistor with variable load
• Thickness gauge, part number
UKOG1013.B
• 0.3 mm, flat- feeler gauge
• Grounded wrist strap
• Anti-static mat or other anti-static
work surface
• Calibration tubing, part no.
3-2-92-479
• Precision 250 μL gas tight syringe.
part no. Hamilton #1725 (or
equivalent)
• Oscilloscope (dual trace)
• Razor blade
• Metric Phillips-head screwdriver, #0
• Metric Phillips-head screwdriver, #1
• Metric Phillips-head screwdriver, #2
• UPP extractor, part no. UKOG1020.A
• Wire harness connector extractor, part
no. UKOG1021.A
• Torque screwdriver, 0-15 kgf-cm or
0-20 in-lb
• Metric ball point Allen wrench,
1.5 mm
• Slide Clamp Resetting Tool, part no.
020416132
• Soldering Iron,
temperature-regulated, 600° - 700°F,
20 - 48 Watts, 1/32” tip
• Yellow paint pen
