3 Nurse Call
3-4 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
Nurse Call
The optional nurse call feature enables a user to connect the pump to a nurse
call system at a care area. To connect the pump to your facility’s Nurse Call
system authorized service personnel must:
Q Install a jumper as described in “Nurse Call” on page 4-1.
Q Construct or purchase a cable as shown in “Nurse Call” on page 4-1.
Q Connect the cable to the pump’s communications port and the
facility’s system.
Note: Ensure that the connector locking screws are tightened before use.
A manual explaining the computer monitoring feature is available from
Baxter upon request.
Administration Sets
The FLO-GARD 6201 Single Channel Volumetric Infusion Pump is designed
for use with Baxter’s standard administration sets that contain an “s” as the
last character of the code number, for example, 2C5537s.
