07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-5
Illustrated Parts Breakdown Overview
Table 11-3 Parts List - Rear Housing Assembly
Item Svc. Part # Mfg. Part # Description Qty
1 CPWBN104.B F043130001 PCB, ASSEMBLY-Terminal 1
2 CPWBN104.C F049130012 PCB, ASSEMBLY-Backkup Aud Alrm 1
3 CPWBN105.A F043130004 PCB, ASSEMBLY-Audible Alarm 1
4 GCABB104.C F044624006 Rear Housing 1
5 GLEGG100.D F044630001 FOOT, Rubber 2
6 LANGQ103.A F044211001 Main Ground Plate 1
7 LANGQ103.B F044220003 Vol/lock Ground Plate 1
8 LANGT102.B F044220005 BRACKET, XFORMER 1
9 PGUMM103.D F044620003 BOOT, Rubber-Main Buzzer 1
10 PGUMM103.E F044620004 BOOT, Rubber-Backup Buzzer 1
11 QCNW1043.B F044140001 GND WIRE, Front Housing 1
12 QCNW1052.B F044140003 GND WIRE, XFORMER 1
13 QCNW1058.A F044140002 Gnd Wire, Pwr Receptacle 1
14 QCNW1093.A F042140005 Buzzer Harness, 1
15 QCNW1095.A F044140007 GND WIRE, Pole Clamp 1
16 QCNW1117.A 5003415001 Flat Ribbon Cable 1
17 QSWP1008.A 5009470002 Switch, Panel Lock 1
18 RTRNP100.E 5009462001 AC Transformer 117V, 60Hz 1
19 RVRC1350.A 2501003200 POT, Volume Control 1
20 XBPBN30P.C 4009310029 Screw, Pan Head-M3X8 with brass washer assy 2
21 XBPBN40P.E 4009310003 SCREW, Pan Head-M4X8 w/washer assy 7
22 XUPSD30P.B 4009310020 SCREW, Pan Hd-Tapping M3X8 5
23 XUPSD40P.A 4009310021 SCREW, Pan Hd-Tapping M4X8 2
24 PZETL102.D 3004010007 FILM, Batt. Compartment Insulation 1
25 XWHSD300.C 4009330001 WASHER, Rubber Foot-M3 4
26 PZETV102.A 3004010008 FILM, Power Trans Insulation 1
27 XEPSD30P.A 4009310018 SCREW, Pan Hd-Tapping M3X8 4
