07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 5-1
Chapter 5
Chapter 5 Configuration Option Feature
Overview
This section describes the configuration option feature of the pump, which
allows qualified personnel to inspect and/or modify certain pump operating
parameters to suit customer requirements.
These parameters and their setting options are shown in Table 5-1. The
factory settings made at the time of manufacture are also shown in the table.
Note: Although the configuration option data is stored in battery backed-up RAM, it
may be lost when the main battery connector (CN302) is disconnected from
the CPU board without turning off the pump. The configuration option data is
also lost when the lithium backup battery connector (CN304) is disconnected
while the main battery is disconnected. Therefore, we advise that the configu-
ration options be recorded before beginning repair procedures and reset
when repairs are complete.
Appendix C,“Configuration Options Data Sheet” is a data sheet which may be
reproduced and used to record the pump’s configuration settings.
Reviewing the Configuration Option Settings
To review the configuration option settings, the pump must be powered on
and stopped. Press
TIME and TOT VOL/STATUS simultaneously for one
second. The message REVIEW CONFIG is displayed in the Message
Display. The option description is displayed in the first line of the Message
Display when the
NEXT or SEC START key is pressed, beginning with
OCCLUSION. The current setting is displayed on the second line.
To view the next setting, press the
NEXT or SEC START key. Each press of
the
NEXT or SEC START key causes the pump to advance to the next
setting, in the order shown in Table 5-1, starting with Occlusion Alarm
Level. To exit the inspection mode, press the
STOP key or press TIME and
TOT VOL/STATUS simultaneously.
