07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 8-9
Removal/Replacement Procedures Disassembly/Reassembly
9.3 Remove the masking tape before the silicone starts to form a
skin.
9.4 Keep the pump on its back for 30 – 45 minutes.
Replacement of Pump Head Door Cover
1. Open the pump head door.
2. Remove five screws that secure the pump head door cover to the pump
head door. (Figure 11-5 , item 28) Do not remove the screw affixing the
metal plate in the recess at the bottom of the door (Figure 11-5 , item 27).
3. If clicking is heard during pump operation and is irritating, you may be
able to stop this by following the procedure below, otherwise proceed to
the next step:
3.1 Remove the seven screws (item 26 in Figure 11-5 ) from the
outside of the door.
3.2 Remove one screw (item 27 in Figure 11-5 ) from the inside of
the door.
3.3 Note how the springs are currently installed to ensure they are
installed correctly later.
3.4 Remove the five springs (item 18 in Figure 11-5 ) and the back
plate (item 17 in Figure 11-5 ).
3.5 Apply a very small quantity of silicone grease (part no. G-501)
to the four blue pads (item 20 of Figure 11-5 ) located inside
the back plate slot with a brush.
3.6 Ensure that the back plate is clean.
3.7 Ensure that the five springs are installed correctly.
3.8 Ensure that the safety clamp plate (item 15 in Figure 11-5 ) and
any spacers are in place.
3.9 Align the notch in the back plate with the tongue in the door
and secure the back plate in place with the 8 screws (items 26
and 27 in Figure 11-5 ) removed previously. Torque to 6 kg-cm
(5.2 lbs.-in.)
3.10 Proceed to the next step.
Perform this step carefully so as to avoid losing the springs held in place by the
screws you just removed.
