07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 2-3
Description Controls and Indicators
Controls and Indicators
All controls and indicators are described in the following sections and are
shown in Figure 2-1, Figure 2-2, and Figure 2-3. Service personnel should
be familiar with the pump’s features and operation before servicing the
pump. The pump’s serial number is recorded on a label on the back of the
pump.
Front Controls and Indicators
See Figure 2-1 for the locations of the controls and indicators described
below.
Item Function
1. Message Display Shows all messages.
2. BACKLIGHT key Provides backlighting of the displays when the pump is used in darkened areas. The
key toggles the backlighting on and off. When the pump is operating on battery power,
the backlight remains on for 60 seconds and turns off automatically to conserve battery
power.
3. SILENCE Key Temporarily silences an audible alarm or alert for two minutes. All visual alarm or
alert information remains displayed.
4. NEXT Legend When the NEXT legend is lit, the TOT VOL/STATUS key functions as a scrolling
key to advance to the next step of a programmed delivery profile (PDP) or
configuration option. See Chapter 5, “Configuration Option Feature”.
5. TOT VOL/STATUS
Key
Dual-function key. During operation, this key causes total volume delivered and
current settings to display when pressed. It is also used to select a next step in Review
Configuration, Modify Configuration and Programmed Delivery Profile modes. The
word “NEXT” above the key is illuminated when the key is functioning as a NEXT
key.
6. CLEAR TOT VOL Key Resets the total volume delivered to zero when the pump is stopped.
7. TIME Key Enters desired time interval for an infusion during Volume-Time or Rate-Time
programming.
8. STOP Key Stops the pump. The STOPPED message appears when the key is pressed. An alert
sounds when the pump is stopped for more than two minutes. Clears all programming
alerts while pump is running.
9. Door Latch Opens and closes pump door.
10. ON-OFF/CHARGE
Key
Turns the pump on and off. The internal battery charger remains on regardless of the
ON-OFF/CHARGE key as long as the pump is plugged in.
11. Battery Icon Yellow LED, always lit while the pump is operating on battery power.
12. Plug Icon Green LED, always lit while the pump is plugged in and the battery is charging.
