2 Controls and Indicators
2-4 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
13. MONITOR Legend Lights for at least 2 seconds each time the host computer communicates with the pump
when the pump is in monitor mode.
14. COMPUTER
CONTROL Legend
Flashes when the pump is initiating communications with a host computer to enter the
computer control mode. It is constantly illuminated when the pump is in computer
control mode.
15. SEC START Key Starts the delivery of the secondary solution.
16. SEC VTBI Key Allows programming of the secondary VTBI.
17. OPTIONS Key/Legend Allows the pump to operate in special modes, when enabled. The OPTIONS legend
lights when the key is enabled.
18. SEC RATE Key Allows programming of the secondary infusion rate.
19. CLR Key Clears any locked in values and programming values currently being entered.
20. Numerical Keypad The numerical values for rate, VTBI, and time are entered with these keys.
21. PRI VTBI Key Allows programming of the primary VTBI.
22. PRI RATE Key Allows programming of the primary infusion rate.
23. PRI START Key Starts the primary infusion.
24. Main Display Shows rate, volume to be infused (VTBI), and total volume infused for primary and
secondary infusion programs.
25. ALARM LED Red LED that blinks on and off during an alarm, accompanied by a visual message
display and a repeated sequence of three beeps. An alarm indicates that the pump
requires immediate attention.
26. PUMPING LED Green LED which is constantly lit while pump is running.
27. ALERT LED Yellow LED which lights during alerts, accompanied by a message display and a
repeated single beep. An alert indicates that the pump needs timely attention.
Item Function
