2 Technical Specifications
2-2 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 07-19-B1-688
Leakage Current Typically less than 50 μA (using UL-544 specified test methods)
Power Consumption 30 W
Weight 5.3 kg (11.6 lbs)
Dimensions 20 cm W x 13 cm D x 29 cm H (7.9" W x 5.1" D x 11.4" H)
Flow Rate Range Primary program: 1 - 1999 mL/hr in 1 mL/hr increments and
1 - 99.9 mL/hr in 0.1 mL/hr increments. Upper limit can be reduced by
authorized service personnel.
Secondary program: 1 - 999 mL/hr in 1 mL/hr increments and
1 - 99.9 mL/hr in 0.1 mL/hr increments.
VTBI Range 1 - 9999 mL in 1 mL increments and 1 - 99.9 in 0.1 mL increments for both
primary and secondary. Upper limit can be reduced by authorized service
personnel.
Ramp PDP Parameter Ranges
(available only on pumps running
software versions 1.09 or later)
• Total VTBI: 100 - 9,999 in 1 mL increments. Upper limit can be reduced
by authorized service personnel.
• Delay Time: 00:00 - 08:00 hours in minute increments.
• Run Time:
• 01:00 - 16:00 hours in minute increments.
• 01:00 - 24:00 hours in minute increments (software versions 1.14 and later).
• Ramp Up: 00:00 to 45% of the Run Time minus Ramp Up, in minutes.
• Ramp Down: 00:00 to the Run Time minus Ramp Up, in minutes.
Air-in-Line Detection Factory set to NORM which causes the device to alarm on air bubbles
approximately 75 μL or larger. The MIN setting causes the device to alarm
on bubbles approximately 50 μL or larger.
Fuse 0.5 A Slo-Blo
Nurse Call 9-pin D connector, Pin 1: N/O, Pin 4: N/C, Pin 9: Common
Contact rating: 0.4A at 30 VAC, 2A at 30 VDC resistive load (internal
activation required)
Item Characteristic
