07-19-B1-688 FLO-GARD 6201 VOLUMETRIC INFUSION PUMP SERVICE MANUAL 11-3
Illustrated Parts Breakdown Overview
Table 11-2 Parts List - Front Housing Assembly (F049990010)
Item Svc. Part # Mfg. Part # Description Qty
1 CPWBN104.A F042130005 Display PCB Assembly 1
2 CPWBX104.A F042130006 CPU PCB Assembly 1
3 CPWBX104.B F041130007 Sensor PCB Assembly 1
4 GCABA104.A F041624001 Front Housing 1
5 GLEGG100.D F044630001 FOOT, Rubber 2
6 LANGT103.B F042220001 BRACKET, MOUNTING-Pump Head 1
7 LDAi1008.A F044620014 SPACER, PCB 3
8 PGUMM103.J F044630002 SEAL, Rubber, Housing 1
9 PSPAF103.A F044230001 SPACER, Pump Head 1
10 PSPAN103.A F049620013 SPACER, Double Locking, PCB 2
11 PSPAB103.A 4009320001 SPACER, Large PCB 7M 5
12 RDENC100.D F049130002S DC Power Supply, 105-130V 1
13 XBPBN30P.A 4009310001 SCREW, Pan Head, M3 x 6 w/ washer assy 1
14 XBPBN40P.E 4009310004 SCREW, Pan Head, M4X10 2
15 XBPSD30P.D 4009310005 SCREW, Pan Head, M4X6 10
16 XBPSD30P.G 4009310038 Screw, Pan Head, M3X6 1
17 XUPSD30P.B 4009310020 SCREW, Pan Hd-Tapping, M3X8 15
18 XWHSD300.C 4009330001 WASHER, Rubber Foot, M3 4
19 07-26-01-081 07-26-01-081 LABEL, Directions for Use 1
20 XEPSD30P.A 4009310018 SCREW, Pan Hd-Tapping, M3X8 4
21 PZETL100.A F044610001 Cover, LCD Insulation 1
22 PSEL1007.A 3004090001 SEAL, DUST, LCD 1
23 UBATL100.A 5009480002 Lithium Battery 1
