MX680RD User’s Manual
3.5 Multiple Displays (through Intel Video Graphic):
1. Due to the limitations of Intel video driver, 4 display outputs are the maximum of multiple
video outputs available with MX680RD board.
2. It is recommended that if user prefer to have multiple display outputs, the physical
display devices (DP monitors, LVDS or eDP panels) can be connected to the desired
video port before power on the system. (maximum 4 display output connections).
NOTE:
LVDS panel and eDP panel can’t be used simultaneously. Only either one of them can be
connected at once.
3. Once the system is loaded into Windows desktop, user may conduct further adjustments
through Window’s “Display Settings” (right click on the Windows desktop), and/or
through “Intel Graphics Command Center” (through Windows Start Menu).
3.6 The optional Audio Control Console Installation:
1. In order to install the optional Realtek Audo Control Console, user needs to install the
provided “MS Visual C++ 2015 (14.0.30704.0) first (by double click on the appx file to
install).
2. And then install Realtek Audo Control Console (by double click on the appx file to
install).
3. In order to access the Realtek Audio Control Console at first time, an internet connection
is required.
