• 1.4.3.4 Internal Headers
Label Note Page
ATX12V1 ATX 4-Pins Power Connector 2 x 2 Mini Fit 4.20mm Straight
Type Power Header.
(12V~24V, A PSU with 23A min
(34A for CPU peak current) on its
“12V2” rail (for connecting with
this 2x2 connector) is
recommended)
37
F_PANEL1 Front Panel Connector 2 x 5 Box Header, Pitch 2.54mm 40
CPU_FAN1 CPU Fan Connector 1 x 4 wafer, Pitch 2.54mm 42
SYS_FAN1 System Fan Connector 1 x 4 wafer, Pitch 2.54mm 42
COM1
COM2
Serial Port Connectors 1, 2 2 x 5 wafer header, Pitch 2.00mm 45
SATA1
SATA2
Serial ATA 3.0 Connectors 1, 2 7-pin header (Red) 43
USB3_P56 Front USB3.2 Header 2 x 10 box header, Pitch 2.00mm 45
USB1112 Front USB2.0 Header 2 x 5 box header, Pitch 2.54mm 44
LVDS1 LVDS Panel Connector 2 x 20 wafer header,
Pitch 1.25mm
46
JBKL1 LVDS Panel Backlight Connector 1 x 5 wafer header, Pitch 2.00mm 46
FP_AUDIO1 Front Panel Audio Connector 2 x 5 header, pitch 2.54mm 43
JAMP1 Audio Amplifier Connector 1 x 4 wafer header, pitch 2.00mm 44
JDIO1 Digital IO (GPIO) Header 2 x 6 wafer header, pitch 2.00mm 47
SMBUS1 SMBus Header 1 x 5 wafer header, 2.00mm 47
I2C1 I2C Connector 1 x 4 wafer header, 2.00mm 48
JCASE1 Chassis Intrusion Connector 1 x 2 wafer header, 2.54mm 48
