MX680RD User’s Manual
1.4 Mainboard Overview
Before you install the mainboard, study the configuration of your chassis to ensure that the
mainboard fits into it.
Make sure to unplug the power cord before installing or removing the mainboard. Failure
to do so can cause you physical injury and damage mainboard components.
1.4.1 Mounting Holes
Place the screws into the mounting holes indicated by red squares to secure the mainboard to
the chassis.
Do not overtighten the screws! This may damage the mainboard.
