BDCOM S6508 Switch Hardware Installation Guide
Localtion LED Name Decription
LINK
Green means that the Port is active（the link is connected and
operational）.
Off means that the Port is No link.
On the top of
ever SFP
module
Connector
ACT
Green means that the Port is Activity, Port is transmitting or
receiving data.
Off means that the Port is not Activity.
PWR
Green means that the Module is Power On
.
Off means that the Module is Power Off
.
SYS
Green means that the Module is active
Off means that the Module is No active.
On the top of
Panel
SWAP
Green means that the module can be hot-pluged out
.
Off means that the module can not be hot-pluged out
.
3. Button
Table 1-7 LS65－4GE－SFP module button description
Button name Button Decription
SWAP
Use for hot plug. Press the SWAP button, then system will light the
SWAP Led. When the SWAP Led light On, the module can be hot
pluged out.
1.6.4 16-Port 100BASE SFP Module （LS65-16FE-SFP）
Figure 1-14 is 16-Port 100BASE SFP Module
（
LS65-16FE-SFP
）
front view.
- 17 -
