BDCOM S6508 Switch Hardware Installation Guide
 4-Port Gigabit SFP Module
（
LS65-4GE-SFP
）
: is a type of the LPU module.
LS65-4GE-SFP module provides 4 switched, full-duplex Gigabit Ethernet
Ports
. Support Gigabit SFP module.
 32-Port 10/100BASE-TX Module
（
LS65-32FE-TX
）
: is a type of the LPU
module.LS65-32FE-TX module provides 32 switched 10/100-Mbps autosensing,
full or half-duplex ports.
 16-Port 100BASE SFP Module
（
LS65-16FE-SFP
）
:is a type of the LPU
module.LS65-16FE-SFP module provides 16 switched 100-Mbps ports.Support
100BASE SFP module.
1.6.1 System Management and Switching Unit module (LS6508-MSU)
Figure1-11 is System Management and Switching Unit module
（
LS6508-MSU
）
front
view. LS6508-MSU is the center of Ethernet Switching
.
Manage and Control the S6508
system.The chassis provides 2 Slot
（
Slot 5 and Slot6
）
for the LS6508-MSU modules.
When two LS6508-MSU modules are all pluged in Slot 5 and Slot 6, one module will
operate at Master status, the other module will operate at Slave status.Then the
system will support Hot-backup.
Two LS6508-MSU modules are configured in one chassis is recommended to get the
system’s high reliability.
