BDCOM S6508 Switch Hardware Installation Guide
Chapter 3 Installing switch
Before install the S6508, please confirm that the chapter 2 has be readed. Please confirm
that the principals are all reached.
3.1 Installing flow
Prepartion
before
install
S6508
Install rack
Install s6508
on rack
Grounding switch
Connect AC power Connect DC power
Connect MSU
cable
Plug info module
Plug cable on
module
Bind cable
Post-check
Install finished
Connect
power
supply(AC/
DC)
