BDCOM S6508 Switch Hardware Installation Guide
1.4 S6508 Switch Hareware composing
S6508 Switch Hardware system include Chasssis, Power module and System module.
S6508 Chassis Weight: 35KG; Power module Weight:3.2KG; One System module
Weight: about 2.9KG. Chassis fully configured Weight 68KG(10 modules, 2
AC-Power modules). The final package with the fully configured chassis weight 86KG
(the package weight 17KG; adjunct case weight 1KG).
1.4.1 Rack
S6508 can be installed in
19-inch Rack
.
ShangHai Baud Data Communication Co.,
Ltd. can provide 4 type
standard
19-inch Rack:
2.2m metal Rack
（
H
×
W
×
D=2200mm
×
600mm
×
600mm
）
2.0m metal Rack
（
H
×
W
×
D =2000mm
×
600mm
×
600mm
）
1.8m metal Rack
（
H
×
W
×
D =1800mm
×
600mm
×
600mm
）
1.6m metal Rack
（
H
×
W
×
D =1600mm
×
600mm
×
600mm
）
1.4.2 Chassis
The S6508 Chassis is 19 Inchs Chassis, The chassis hight is 670mm
（
15U
）
, width is
440mm, depth is 455mm. The chassis include Airflow exhaust, Fan assembly, System
module Slots, Airflow intake and Power Supply Slots.
System module Slots are the main of the chassis. The system modules can be pluged
in the Slots.
On the bottom of chassis, there are two Power supply Slots, Between the Power
supply Slots and the System module Slots, there is the airflow intake.
Fan Assembly is on the top of System module Slots. The Fan Assembly have 6 fans.
On the top of Fan Assembly,there is the airflow exhaust.
- 3 -
