IPC@CHIP SC123/SC143
Hardware Manual V1.06 [18.02.2010]
©2000-2008 BECK IPC GmbH Page 14
4.4 DMA
Ball Pin
Name
Ball
Pin
Type
Description
PIO12
(1)
DRQ0
(1)
C7
I/O [4mA]
IN
Direct Memory Request 0 (Schmitt Input with Pull-up)
This pin can be used with DMA channel 0 as DRQ0.
It can also be used as PIO[12].
PIO29
(1)
DRQ1
(1)
A6
I/O [4mA]
IN
Direct Memory Request 1 (Schmitt Input with Pull-up)
This pin can be used with DMA request 1 as DRQ1.
It can also be used as PIO[29].
PIO7
(1)
DRQ2
(1)
B6
I/O [4mA]
IN
Direct Memory Request 2 (Schmitt Input with Pull-up)
This pin can be used with DMA channel 2 as DRQ2.
It can also be used as PIO[7].
PIO8
(1)
DRQ3
(1)
A4
I/O [4mA]
IN
Direct Memory Request 3 (Schmitt Input with Pull-up)
This pin can be used with DMA channel 3 as DRQ3.
It can also be used as PIO[8].
Table 4-3: Pin Description of DMA Request Pins
4.5 Interrupts
Ball Pin
Name
Ball
Pin
Type
Description
PIO9
(1)
PFI
(1)
E1
I/O [4mA]
IN
Power-fail Interrupt (Schmitt Trigger Input, Active HIGH with Pull-
up)
This pin can be used as a power fail interrupt.
PFI is a non-maskable interrupt (NMI). It can be used to save non-
volatile data to the internal flash or external memory devices (see
chapter 6.7).
It can also be used as PIO[9].
INT3
(1)
INT1
(1)
C4
B5
IN
IN
Interrupt In (Schmitt Trigger Input, Active HIGH with Pull-down)
These pins are external interrupt input requests.
Note: INT3 is shared with the USB controller and INT1 is shared
with the MAC 1 controller.
PIO30
(1)
INT5#
(1)
A3
I/O [4mA]
IN
Interrupt In (Schmitt Input with Pull-up, Active LOW)
This pin can be used as INT5. Note: This interrupt is shared with
UART 3.
It can also be used as PIO[30].
Table 4-4: Pin Description of Interrupts
4.6 UART0 Interface
Ball Pin
Name
Ball
Pin
Type
Description
TXD0
(1)
A8
OUT [2mA]
Transmit Data 0 Out
This pin provides serial Transmit Data to the system from serial
port 0.
RXD0
(1)
C8
IN
Receive Data 0 In (Schmitt Trigger Input, Active HIGH with Pull-up)
This pin provides serial Receive Data from the system to serial
port 0.
RTS0#
(1)
A7
OUT [2mA]
Ready to Send 0 Out
This pin provides the Ready to Send output for serial port 0. This pin
provides the handshaking output for serial port 0.
CTS0#
(1)
B7
IN
Clear to Send 0 In (Schmitt Trigger Input, Active High with Pull up)
This pin provides the Clear to Send input for serial port 0. This pin
provides the handshaking input for serial port 0.
Table 4-5: Pin Description of UART0
Note 1: 5V tolerant
