IPC@CHIP SC123/SC143
Hardware Manual V1.06 [18.02.2010]
©2000-2008 BECK IPC GmbH Page 21
4.20 Programmable I/O Pins
The SC1x3 provides 31 individually programmable I/O pins. Each PIO can be programmed with the attributes
function (enabled/disabled) and direction (input/output). Each PIO has a weak internal pullup resistor.
PIOs as input have Schmitt Trigger features. PIOs that programmed as output can drive 4mA (see chapter
8.2.4). During and after reset, all PIO pins are set to PIO as inputs with pull-ups by default.
PIO Sharing Designations
PIO Number
Shared Function Name
0
TMRIN1
1
TMROUT1
2
PCS[6]#
3
PCS[5]#
4
PCS[4]#
5
PCS[7]#
6
ARDY
7
DRQ2
8
DRQ3
9
PFI
10
TMROUT0
11
TMRIN0
12
DRQ0
13
I2CDTA
14
CAN1TXD
15
CAN1RXD
16
-
17
-
18
CTS3#/SLVSEL#
19
RTS3#/SCK
20
RTS2#
21
CTS2#
22
TXD2
23
RXD2
24
-
26
-
27
TXD3/SD0
28
RXD3/SDI
29
DRQ1
30
INT5#
31
I2CCLK
Table 4-19: List of PIO sharing designations.
