Beck IPC SC123 User Manual

IPC@CHIP SC123/SC143
Hardware Manual V1.06 [18.02.2010]
©2000-2008 BECK IPC GmbH Page 44
8 Characteristics
8.1 Absolute Maximum Ratings
SC123 and SC143
Parameter
Min
Max
Unit
Supply Voltage (V
DD
)
-0.2
3,6
V
Storage Temperature
-55
+125
°C
Supply current (V
DD
= 3.6V)
0.6
A
Voltage on any pin with respect to ground
-0,5
V
DD
+0,3
V
Voltage on 5V-tolerant pin with respect to
ground
-0,5
6
V
Table 8-1: Absolute Maximum Ratings
8.2 Recommended Operating Ranges
8.2.1 Voltage and Temperature
SC123 and SC143 (Under operating ranges unless otherwise noted)
Note: Exposure to conditions beyond those listed here may adversely affect the lifetime and reliability of the
device.
Parameter
Unit
Supply Voltage (VDD)
3.3 ±5%
V
Operating Temperature
-25..+85
°C
Ball Input Capacitance
4
pF
Table 8-2: Recommended Operating Ranges
8.2.2 Supply Current
Parameter
Min
Typ
Max
Unit
Current into VDD @3,3V
(disconnected ETH0, 96MHz CPU Clock)
0.08
0.20
0.4
A
Current into VDD @3,3V
(10MBit connected ETH0, 96MHz CPU Clock)
0.08
0.30
0.4
A
Current into VDD @3,3V
(100 MBit connected ETH0, 96MHz CPU Clock)
0.08
0.27
0.4
A
Current into VDD @3,3V
(disconnected ETH0, 48MHz CPU Clock)
0.08
0.15
0.35
A
Current into VDD @3,3V
(ETH0 in power down, 24MHz CPU Clock*)
0.08
0.08
0.35
A
Table 8-3: Supply Current
*Note: At a clock rate of 24MHz no network communication with 100MBit is possible.
