IPC@CHIP SC123/SC143

Hardware Manual V1.06 [18.02.2010]

10.2 Cover Description

Figure 10-2: Cover

Cover print variations:

1. IPC@CHIP SC123

2. IPC@CHIP SC143

Configuration

2 MByte Flash Memory

8 MByte Flash Memory

The suffix LF designates a lead free (RoHS compliant) type of IPC@CHIP. For lead free soldering see

chapter 13: Reflow Profile.

The suffix IEC designates a preinstalled CoDeSys license

HXX is an optional hardware version of the SC1x3

IPC@CHIP SC123

Germany

LF IEC HXX

SN:000SSSSS
