IPC@CHIP SC123/SC143
Hardware Manual V1.06 [18.02.2010]
©2000-2008 BECK IPC GmbH Page 20
4.18 PHY Power (Internal PHY)
Ball Pin
Name
Ball
Pin
Type
Description
VDD1A
J16
PWR
Power I/O: +3.3 volt power supply
(requires a separate via to power plane)
VDD2A
J15
PWR
Power I/O: +3.3 volt power supply
(requires a separate via to power plane)
VSS3A
K15
PWR
Power VSS
(requires a separate via to power plane)
VSS4A
H15
PWR
Power VSS
(requires a separate via to power plane)
Table 4-17: Pin Description of PHY Power Pins
4.19 Power
Ball Pin
Name
Ball
Pin
Type
Description
VSS
E15
PWR
Power VSS
VSS
N15
PWR
Power VSS
VSS
C13
PWR
Power VSS
VSS
R13
PWR
Power VSS
VSS
C6
PWR
Power VSS
VSS
R5
PWR
Power VSS
VSS
F3
PWR
Power VSS
VSS
N3
PWR
Power VSS
VSS
A1
PWR
Power VSS
VSS
H10
PWR
Power VSS (Thermal Ball)
VSS
J10
PWR
Power VSS (Thermal Ball)
VSS
K10
PWR
Power VSS (Thermal Ball)
VSS
H9
PWR
Power VSS (Thermal Ball)
VSS
J9
PWR
Power VSS (Thermal Ball)
VSS
K9
PWR
Power VSS (Thermal Ball)
VSS
H8
PWR
Power VSS (Thermal Ball)
VSS
J8
PWR
Power VSS (Thermal Ball)
VSS
K8
PWR
Power VSS (Thermal Ball)
VDD
C15
PWR
Power I/O: +3.3 volt power supply
VDD
R15
PWR
Power I/O: +3.3 volt power supply
VDD
C5
PWR
Power I/O: +3.3 volt power supply
VDD
C3
PWR
Power I/O: +3.3 volt power supply
VDD
E3
PWR
Power I/O: +3.3 volt power supply
VDD
R3
PWR
Power I/O: +3.3 volt power supply
Table 4-18: Pin Description of Power Pins
