Bender RCMS460 - Connection W; (AC;DC Current Sensitive)

Installation and connection
29
RCMS460-490_D00067_03_M_XXEN/12.2017
4.4.4 Connection W…AB series measuring current transformers
(AC/DC current sensitive)
The connections k and l at the residual current monitor must
not be interchanged.
(not for W20AB)
Coding
