Operation
41
RCMS460-490_D00067_03_M_XXEN/12.2017
6.3.3 Test procedure
A test serves to check the device function (hardware components) of the
RCMS. A test can be activated as follows:
Select standard display and then press the "TEST" button on the RCMS
front panel for at least one second.
Press an external test button connected to the RCMS…
Send a test command via the BMS bus.
RCMS…-D… only: Select "TEST" from the control menu.
The RCMS… responds as follows:
"ALARM 1" and "ALARM 2" LEDs light up.
All alarm relays switch (this function can be deactivated, refer to
page 68).
An alarm message is sent on the BMS bus.
An entry is stored in the history memory with the suffix "TEST".
RCMS…-D…: The progress of the test is indicated on the display.
The RCMS460…-D then displays the set response value for the highest
functioning measuring channel.
Press the "" button several times to display the correct functioning of
the other measuring channels.
TEST 12/12
Residual current
100 mA
Addr.: 2 Chan.: 12
