Operation
78
RCMS460-490_D00067_03_M_XXEN/12.2017
The following menu items are displayed for the RCMS…-L:
Use the Up/Down buttons to select the appropriate function or device setting
and confirm with the "↵" button.
Menu item Function Page
Exit Exit menu mode -
1.Alarm/
meas.values
Displays the following for each measuring chan-
nel, if applicable: prewarning, alarm, measured
value, digital input status, response value, chan-
nel disabled, CT connection fault.
49
2.% Bar graph For each of the 12 measuring channels, the
reached per cent value of the set alarm value I
Δn2
(alarm) and I
Δn1
(prewarning) is indicated. In case
of digital inputs, the status is indicated.
49
3.Harmonics Displays the following for the selected measuring
channel: Measured value, THF (Total Harmonic
Factor), DC component, fundamental component
and harmonics in mA.
51
4.Settings Settings for this RCMS… are made here. 53
5.Control This menu offers various control options, such as
TEST, RESET, TEST COMMUNICATION.
74
6.Info Information on the device. The same display is
obtained by pressing the INFO button in the ope-
rating mode (see "Displaying standard informa-
tion" on page 34).
79
