Data
98
RCMS460-490_D00067_03_M_XXEN/12.2017
AC/DC sensitive measuring current transformers for RCMS460/490
Flexible measuring current transformers (pulsed DC sensitive) for
RCMS460/490
WF… series measuring current transformers consist of one flexible W…F se-
ries measuring current transformer and one RCC420 signal converter.
Type Inside diameter (mm) Design type Art. No.
W20AB 20 circular B98080008
W35AB 35 circular B98080016
W60AB 60 circular B98080026
W120AB 120 circular B98080041
W210AB 210 circular B98080040
W35ABP 35 circular B98080051
W60ABP 60 circular B98080052
Type Length (mm)
Supply voltage U
S
Art. No.
WF170-1 170
AC 16…72 V, 42…460 Hz
DC 9,6…94 V
B78080201
WF170-2 170
AC 70…300 V, 42…460 Hz
DC 70…300 V
B78080202
WF250-1 250
AC 16…72 V, 42…460 Hz
DC 9,6…94 V
B78080203
WF250-2 250
AC 70…300 V, 42…460 Hz
DC 70…300 V
B78080204
WF500-1 500
AC 16…72 V, 42…460 Hz
DC 9,6…94 V
B78080205
