57
Throw Ratio
54”±5% Diagonal @ 2M
(Wide)
Contrast: Preset
Brightness: Preset
Full white
Zoom Ratio >1.10:1
Contrast: Preset
Brightness: Preset
Full white
Keystone Distortion
(W2-W1) / (W1+W2)
<1.0%
Contrast: Preset
Brightness: Preset
Full white
Vertical TV Distortion
(H1+H2-2×H3)/2H2
<1.0%
Contrast: Preset
Brightness: Preset
Full white
Visible Range 1~8m
Contrast: Preset
Brightness: Preset
Chromo 84 X pattern
Clearly Focus Range
Pixel clear and uniform
at 1.5~6m
Contrast: Preset
Brightness: Preset
Chromo 84 X pattern
Color and Gray Check
Should be clear and
bright
Brightness: Preset
Contrast: Preset
Chromo 256 gray
pattern
DMD Image Quality
See
Defect Classification
See
Defect Classification
See
Defect Classification
Item Spec. Condition Pattern
PC
640X400Æ 800X600,
compressed 1280X1024;
Composite-Sync;
Sync-on-Green; Interlace
Mode (8514A);
Contrast: Preset
Brightness: Preset
Chromo Test pattern
Video
NTSC/NTSC4.43/PAL(In
cluding PAL-M, PAL-n)
/SECAM/PAL60
Contrast: Preset
Brightness: Preset
VG828 Test pattern
YPbPr
NTSC (480i)/ 480p/ PAL
(625i)/720p,HDTV
(720P/1080i)
Contrast: Preset
Brightness: Preset
VG828 Test pattern
5.3.12.2.1. POWER CONSUMPTION:
Mode Condition Power Consumption LED Color
Standby power - < 15 W Red
Normal - < 285 W Green
5.3.12.3. OPERATIONAL INSPECTION CRITERIA:
